1

Height of center over bed

160

mm

2

Max. distance between centers

750

mm

3

Max. swing over bed

320

mm

4

Max. swing over tool post

175

mm

5

Max. length of work piece

750

mm

6

Size of spindle bore

30 or 40

mm

7

Taper of spindle hole

MT5

8

Type of spindle nose

? 75 x1:4 or ? 82 x1:4

9

Number of spindle speed

12

10

Range of spindle speed

45-1980

r/min

11

Feed speed

range

Cross feed

.02-2.45

mm /r

Longitudinal feed

.03-3.34

12

Size of tool shank (W*H)

20x20

mm

13

Metric thread

Kinds

17

Range

0.5-9

mm

Inch thread

Kinds

32

Range

2-38

Module thread

Kinds

17

range

0.5-9

14

Taper in center sleeve

MT4

15

Max. travel distance of center sleeve

95

 mm

16

Main motor power

4

 kw

17

Cooling motor power

0.125

 Kw

18

Overall dimension (L*W*H)

2400x900x1540

 mm

19

Net weight of machine

1600

 kg
